Description
Dimensions: 46.5 x 28 x 44.5mm
Mounting Type: Through Hole
Maximum Current: 16.4 A
Series: WE-CMBHV
Operating Temperature Range: -40°C → +125°C
Termination Style: Solder Pad
Length: 46.5mm
Height: 44.5mm
Test Frequency: 10 KHz
Depth: 28mm
Inductance: 2 x 1.6 mH
Maximum Operating Temperature: +125°C
Minimum Operating Temperature: -40°C DC Resistance: 2 x 8.5mΩ
This is 2 x 1.6 mH WE-CMBHV Common Mode Choke manufactured by Wurth Elektronik. The manufacturer part number is 744831016164. The given dimensions of the product include 46.5 x 28 x 44.5mm. The product is available in through hole configuration. It also carries 16.4 a maximum current. The product we-cmbhv, is a highly preferred choice for users. The product has -40°c → +125°c of operating temperature range. Moreover, it has solder pad terminal style. Its accurate length is 46.5mm. In addition, the height is 44.5mm. It features a test frequency of 10 khz. The product comes in 28mm depth. The product has a 2 x 1.6 mh inductance value. It has a maximum operating temperature of +125°c. Whereas, the minimum operating temperature of the product is -40°c. It has about 2 x 8.5mω DC resistance .
