2 x 33 mH Wurth Elektronik WE-CMB Common Mode Choke 210 mΩ

Description

Dimensions: 30 x 21 x 35mm

Mounting Type: Through Hole

Maximum Current: 3 A

Series: WE-CMB

Operating Temperature Range: -40°C → +125°C

Termination Style: Solder Pad

Length: 30mm

Height: 35mm

Test Frequency: 10 KHz

Depth: 21mm

Inductance: 2 x 33 mH

Impedance: 210 mΩ

Maximum Operating Temperature: +125°C Minimum Operating Temperature: -40°C DC Resistance: 2 x 210mΩ

This is 2 x 33 mH WE-CMB Common Mode Choke 210 mΩ manufactured by Wurth Elektronik. The manufacturer part number is 744825433. The given dimensions of the product include 30 x 21 x 35mm. The product is available in through hole configuration. It also carries 3 a maximum current. The product we-cmb, is a highly preferred choice for users. The product has -40°c → +125°c of operating temperature range. Moreover, it has solder pad terminal style. Its accurate length is 30mm. In addition, the height is 35mm. It features a test frequency of 10 khz. The product comes in 21mm depth. The product has a 2 x 33 mh inductance value. It has an impedance value of 210 mω. It has a maximum operating temperature of +125°c. Whereas, the minimum operating temperature of the product is -40°c. It has about 2 x 210mω DC resistance .
