AD5204BRZ10, Digital Potentiometer 10kΩ 256-Position 4-channel Serial-3 Wire, Serial-SPI 24-Pin SOIC W

Description

Number of Positions: 256

Typical Dual Supply Voltage: ±2.5V

Dimensions: 15.6 x 7.6 x 2.35mm

Mounting Type: Surface Mount

Power Supply Type: Dual, Single

Resistance Value: 10kΩ

Typical Single Supply Voltage: 3 V, 5 V

Height: 2.35mm

Memory Type: Volatile

Width: 7.6mm

Length: 15.6mm

Package Type: SOIC W

Minimum Operating Temperature: -40 °C Control Interface: Serial-3 Wire, Serial-SPI Maximum Operating Temperature: +85 °C Pin Count: 24 Number of Pots per Package: 4

This is Digital Potentiometer 10kΩ 256-Position 4-channel Serial-3 Wire Serial-SPI 24-Pin SOIC W manufactured by Analog Devices. The manufacturer part number is AD5204BRZ10. The product carries possible position value of 256. While ±2.5v is the typical dual supply voltage. The given dimensions of the product include 15.6 x 7.6 x 2.35mm. The product is available in surface mount configuration. It is a type of dual, single power supply. Its resistance value is 10kω . It has a typical single supply voltage of 3 v, 5 v. In addition, the height is 2.35mm. It is a type of volatile memory type. Furthermore, the product is 7.6mm wide. Its accurate length is 15.6mm. The package is a sort of soic w. Whereas, the minimum operating temperature of the product is -40 °c. It incorporates a serial-3 wire, serial-spi control interface. It has a maximum operating temperature of +85 °c. It contains 24 pins. It contains 4 pots per package .
