Analog Devices AD633JRZ 4-quadrant Voltage Multiplier, 1 MHz, 8-Pin SOIC

Description

Number of Quadrants: 4

Dimensions: 5 x 4 x 1.5mm

Mounting Type: Surface Mount

Maximum Dual Supply Voltage: ±18V

Minimum Operating Temperature: 0 °C

Output Type: Single Ended

Height: 1.5mm

Width: 4mm

Length: 5mm

Package Type: SOIC

Maximum Operating Frequency: 1 MHz

Minimum Dual Supply Voltage: ±8V

Maximum Operating Temperature: +70 °C Pin Count: 8 Number of Elements per Chip: 1

This is 4-quadrant Voltage Multiplier 1 MHz 8-Pin SOIC manufactured by Analog Devices. The manufacturer part number is AD633JRZ. It has 4 number of quadrants included . The given dimensions of the product include 5 x 4 x 1.5mm. The product is available in surface mount configuration. With ±18v of maximum dual supply voltage . Whereas, the minimum operating temperature of the product is 0 °c. Furthermore, it has asingle ended output. In addition, the height is 1.5mm. Furthermore, the product is 4mm wide. Its accurate length is 5mm. The package is a sort of soic. It carries 1 mhz of maximum operating frequency. With ±8v as a minimum dual supply voltage . It has a maximum operating temperature of +70 °c. It contains 8 pins. It consists of 1 elements per chip.
