Bourns PV37W Series 12-Turn Through Hole Trimmer Resistor with Solder Pin Terminations, 5kΩ ±10% 0.25W ±150ppm/°C

Description

Shaft Diameter: 1.8 mm

Orientation: Top Adjust

Mounting Type: Through Hole

Series: PV37

Termination Style: Solder Pin

Number of Turns: 12

Temperature Coefficient: ±150ppm/°C

Length: 6.4mm

Minimum Operating Temperature: -55°C

Power Rating: 0.25W

Maximum Resistance: 5kΩ

Tolerance: ±10%

Maximum Operating Temperature: +125°C

This is PV37W Series 12-Turn Through Hole Trimmer Resistor with Solder Pin Terminations 5kΩ ±10% 0.25W ±150ppm/°C manufactured by Bourns. The manufacturer part number is PV37W502C01B00. The diameter of the shaft is 1.8 mm. The product has a top adjust orientation. The product is available in through hole configuration. The product pv37, is a highly preferred choice for users. Moreover, it has solder pin terminal style. Consist of 12 turns. It exhibits an excellent temperature coefficient of ±150ppm/°c. Its accurate length is 6.4mm. Whereas, the minimum operating temperature of the product is -55°c. Feature 0.25w of power rating. The product offers a maximum resistance up to 5kω. It features ±10% of tolerance value. It has a maximum operating temperature of +125°c.
