Bulgin MPI002/28/GN/12

Description

Illuminated: Yes

Mounting Type: Panel Mount

IP Rating: IP66

Contact Current Rating: 50 mA @ 24 V dc

Series: MPI002

Voltage Rating: 24V dc

Push Button Style: Round

LED Colour: Green

Case Colour: Silver

Push Button Colour: Silver

Panel Cut Out Diameter: 19.2mm

Contact Configuration: SPST

Manufacturer Part No.: MPI002/28/GN/12 Switch Operation: Momentary Terminal Type: Tab Contact Material: Gold Plated Manufacturer Standard Lead Time: 14 Weeks Current Rating: 50mA (DC) Electrical Life: 35,000 Cycles Termination Style: Quick Connect – 0.110″ (2.8mm) Operating Temperature: -30°C ~ 70°C Panel Cutout Dimensions: Circular – 19.20mm Dia Mechanical Life: 750,000 Cycles Type: Vandal Resistant, Illuminated Color – Actuator/Cap: Silver Illumination Type, Color: LED, Green Standard Package: 1 Manufacturer: Bulgin Switch Function: Off-Mom Moisture Sensitivity Level (MSL): 1 (Unlimited) Circuit: SPST-NO Voltage Rating – DC: 24V Ingress Protection: IP66 – Dust Tight, Water Resistant Features: Stainless Steel Mounting Type: Panel Mount, Front Packaging: Bulk Actuator Type: Round, Button, Flush Illumination Voltage (Nominal): 12 VDC

This ismanufactured by Bulgin. The manufacturer part number is MPI002/28/GN/12. Illumination Option yes. The product is available in panel mount configuration. It is IP rated with ip66. The rated contact current is 50 ma @ 24 v dc. The product mpi002, is a highly preferred choice for users. Moreover, the product has a nominal 24v dc voltage rating. This pushbutton has a round style pushbutton and is easy to use. The LED has an adorable green colour. The casing is finished with an adorable silver colour. While it has an adorable silver colour. The panel has a 19.2mm cut-out diameter. The contact is equipped with spst configuration. The product has an assigned mpi002/28/gn/12 manufacturer part number. It provides momentary switch operation. The terminal is a tab type. The product is made from sturdy gold plated materials. It has typical 14 weeks of manufacturer standard lead time. The product has a current rating of 50ma (dc). The product offers long-lasting services of 35,000 cycles. Moreover, it has quick connect – 0.110″ (2.8mm) terminal style. The product has -30°c ~ 70°c operating temperature range. It also has a circular – 19.20mm dia dimensional features. The product also provide mechanical stability with 750,000 cycles. It comes in vandal resistant, illuminated configuration. It is made from silver. It is supplied with led, green illumination. It is available in the standard package of 1. The bulgin’s product offers user-desired applications. It is designed as a off-mom switching function. Its typical moisture sensitivity level is 1 (unlimited). It has an integral spst-no circuit. 24v of DC voltage rating. It is IP rated with ip66 – dust tight, water resistant. The splendid features of the product include stainless steel. The product is available in panel mount, front configuration. In addition, bulk is the available packaging type of the product. The product carries round, button, flush actuator. The nominal illumination voltage of the product is 12 vdc.
