Cornell-Dubilier 100nF Polypropylene Capacitor PP 3kV dc ±10% Tolerance Through Hole 940C Series

Description

Dimensions: 22.5 (Dia.) x 46mm

Lead Diameter: 1.2mm

Series: 940C

Equivalent Series Resistance: 10mΩ

Capacitance: 100nF

Length: 46mm

Voltage: 3kV dc

Minimum Operating Temperature: -55°C

Dielectric: Polypropylene

Mounting Type: Through Hole

Maximum Operating Temperature: +105°C

Tolerance: ±10%

Terminal Type: Through Hole

This is 100nF Polypropylene Capacitor PP 3kV dc ±10% Tolerance Through Hole 940C Series manufactured by Cornell-Dubilier. The manufacturer part number is 940C30P1K-F. The given dimensions of the product include 22.5 (dia.) x 46mm. Furthermore, the lead has 1.2mm diameter. The product 940c, is a highly preferred choice for users. It has 10mω equivalent series resistance. It provides a 100nf of capacitance value. Its accurate length is 46mm. It carries a 3kv dc of voltage. Whereas, the minimum operating temperature of the product is -55°c. The dielectric options include polypropylene. The product is available in through hole configuration. It has a maximum operating temperature of +105°c. It features ±10% of tolerance value. The terminal is a through hole type.
