Crouzet 81519632

Description

Function: 3/2

Solenoid Fitted: Yes

Minimum Operating Temperature: -10°C

Maximum Operating Pressure: 8bar

Maximum Flow Rate: 25NL/min

Minimum Operating Pressure: 1bar

Solenoid Voltage: 24V dc

Mounting Style: Manifold

Number of Ports: 3/2

Manufacturer Series: 81

Actuation Type: Solenoid/Spring

Maximum Operating Temperature: +50°C

Solenoid Power Consumption: 1W HTSUS: 9032.81.0080 RoHS Status: RoHS Compliant Operating Temperature: -10°C ~ 50°C Approval Agency: cUL, UL Mounting Type: Sub-Base Mount Mechanical Life: 50,000,000 Cycles Type: Solenoid Valve Function: 3/2 Normally Closed Orifice Diameter: 0.032″ (0.80mm) Connection Method: – title: 81519632 REACH Status: REACH UnaffectedManufacturer: Crouzet Fluid Type: Air, Inert Gas Moisture Sensitivity Level (MSL): 1 (Unlimited) Operating Pressure: 15 ~ 116 PSI (1 ~ 8 bar) standardLeadTime: 3 Weeks Ingress Protection: IP65 – Dust Tight, Water Resistant Features: Manual Override, Rotatable Connector, Supply Voltage 24VDC Weight: 0.077 lb (34.93 g) Series: – Packaging: Box For Use With/Related Products: – Actuator Type: – ECCN: EAR99

This ismanufactured by Crouzet. The manufacturer part number is 81519632. It performs basic function of 3/2. It includes a fitted solenoid yes . Whereas, the minimum operating temperature of the product is -10°c. It features 8bar maximum operating pressure. The product provides up to 25nl/min maximum flow rate. It has a minimum 1bar operating pressure . It has 24v dc solenoid voltage . The product is available in manifold style. This product features 3/2 number of ports. The product has a 81 manufacturer series. It also features solenoid/spring actuation. It has a maximum operating temperature of +50°c. Its solenoid power consumption is approximately 1w . It is assigned with possible HTSUS value of 9032.81.0080. The product is rohs compliant. The product has -10°c ~ 50°c operating temperature range. It is approved by cul, ul. The product is available in sub-base mount configuration. The product also provide mechanical stability with 50,000,000 cycles. It comes in solenoid valve configuration. It performs basic function of 3/2 normally closed. It bears 0.032″ (0.80mm) of orifice diameter. In addition, it is reach unaffected. The crouzet’s product offers user-desired applications. It accepts fluid as air, inert gas. Its typical moisture sensitivity level is 1 (unlimited). It provides a 15 ~ 116 psi (1 ~ 8 bar) of operating pressure. It has a long 3 weeks standard lead time. It is IP rated with ip65 – dust tight, water resistant. The splendid features of the product include manual override, rotatable connector, supply voltage 24vdc. The typical product’s weight is 0.077 lb (34.93 g). In addition, box is the available packaging type of the product. The product is designated with the ear99 code number.
