Dialight 570-0100-132F, PCB LED Indicator

Description

LED Orientation: Right Angle

Dimensions: 14.62 x 4.97 x 10.17mm

Mounting Type: Through Hole

Dominant Wavelength: 568 / 588 / 625 nm

Intensity: 8.7

Height: 10.17mm

Width: 4.97mm

Length: 14.62mm

Number of Pins: 6

Supply Voltage: 2.5 V

Number of LEDs: 3

LED Colours: Green, Red, Yellow

Viewing Angle: 38 °

This is PCB LED Indicator manufactured by Dialight. The manufacturer part number is 570-0100-132F. It has a right angle LED orientation . The given dimensions of the product include 14.62 x 4.97 x 10.17mm. The product is available in through hole configuration. It has a dominant wavelength of 568 / 588 / 625 nm. The given intensity of the product is 8.7. In addition, the height is 10.17mm. Furthermore, the product is 4.97mm wide. Its accurate length is 14.62mm. It is comprised of 6 pins. Features 2.5 v supply voltage. It consists of 3 LEDs. The LED has a classic green, red, yellow colours. Furthermore, 38 ° is the viewing angle of the product.
