IXYS DSEI12-06A

Description

Mounting Type: Through Hole

Diode Technology: Silicon Junction

Peak Reverse Recovery Time: 50ns

Peak Non-Repetitive Forward Surge Current: 110A

Maximum Forward Voltage Drop: 1.7V

Maximum Continuous Forward Current: 14A

Rectifier Type: Switching

Package Type: TO-220AC

Number of Elements per Chip: 1

Diode Type: Rectifier

Diode Configuration: Single

Pin Count: 2

Peak Reverse Repetitive Voltage: 600V HTSUS: 8541.10.0080 RoHS Status: ROHS3 Compliant Package / Case: TO-220-2 Reverse Recovery Time (trr): 50 ns Operating Temperature – Junction: -40°C ~ 150°C REACH Status: REACH UnaffectedCurrent – Average Rectified (Io): 14A Speed: Fast Recovery = 200mA (Io) Voltage – Forward (Vf) (Max) @ If: 1.7 V @ 16 A Package: Tube Voltage – DC Reverse (Vr) (Max): 600 V Capacitance @ Vr, F: – Moisture Sensitivity Level (MSL): Not Applicable standardLeadTime: 40 Weeks Current – Reverse Leakage @ Vr: 50 µA @ 600 V Mounting Type: Through Hole Series: – Supplier Device Package: TO-220AC Technology: Standard Base Product Number: DSEI12 ECCN: EAR99

This ismanufactured by IXYS. The manufacturer part number is DSEI12-06A. The product is available in through hole configuration. The product utilizes silicon junction diode technology. Moreover, it has a peak reverse recovery time about 50ns . Moreover, a bespoke product has 110a peak non-repetitive forward surge current. It features 1.7v of maximum forward voltage drop. Furthermore, its maximum continuous forward current constitutes 14a. This switching product is highly suited for various professionals in various settings. The package is a sort of to-220ac. It consists of 1 elements per chip. It is designed with a rectifier diode. The diode features a single configuration. It contains 2 pins. While having the peak reverse repetitive 600v. It is assigned with possible HTSUS value of 8541.10.0080. The product is rohs3 compliant. Moreover, the product comes in to-220-2. It has a trr (reverse recovery time) of 50 ns. The product operate at temperatures ranging from -40°c ~ 150°c. In addition, it is reach unaffected. It features a 14a of average rectified current. It has a robust speed of fast recovery = 200ma (io). The product has a maximum forward voltage of 1.7 v @ 16 a. It is shipped in tube package . While it has maximum reverse voltage of 600 v. Its typical moisture sensitivity level is not applicable. It has a long 40 weeks standard lead time. 50 µa @ 600 v is the reverse leakage value of a bespoke product. to-220ac is the supplier device package value. This product use standard technology. Moreover, it corresponds to dsei12, a base product number of the product. The product is designated with the ear99 code number.
