Murata PV12 Series 4-Turn Through Hole Trimmer Resistor with Solder Pin Terminations, 200kΩ ±10% 0.5W ±100ppm/°C

Description

Diameter: 7.6mm

Shaft Diameter: 2.5 mm

Orientation: Top Adjust

Mounting Type: Through Hole

Series: PV12

Termination Style: Solder Pin

Number of Turns: 4

Temperature Coefficient: ±100ppm/°C

Minimum Operating Temperature: -55°C

Power Rating: 0.5W

Maximum Resistance: 200kΩ

Tolerance: ±10%

Maximum Operating Temperature: +125°C

This is PV12 Series 4-Turn Through Hole Trimmer Resistor with Solder Pin Terminations 200kΩ ±10% 0.5W ±100ppm/°C manufactured by Murata. The manufacturer part number is PV12P204A01B00. Its diameter is 7.6mm. The diameter of the shaft is 2.5 mm. The product has a top adjust orientation. The product is available in through hole configuration. The product pv12, is a highly preferred choice for users. Moreover, it has solder pin terminal style. Consist of 4 turns. It exhibits an excellent temperature coefficient of ±100ppm/°c. Whereas, the minimum operating temperature of the product is -55°c. Feature 0.5w of power rating. The product offers a maximum resistance up to 200kω. It features ±10% of tolerance value. It has a maximum operating temperature of +125°c.
