Pepperl + Fuchs SC-System, Isolating Amplifier/Splitter Signal Conditioner, 0 → 20 mA, 4 → 20 mA Input

Description

Output Signal Type: Current

Mounting Type: DIN Rail Mount

Operating Temperature Range: -25 → +70°C

Output Range: 0 → 10 V, 0 → 20 mA, 2 → 10 V, 4 → 20mA

Series: S1SD

Module Type: Transmitter Power Supply

Input Range: 0 → 20 mA, 4 → 20mA

Input Signal Type: Current

Supply Voltage: 16.8 → 31.2V dc

Minimum Operating Temperature: -25°C

Termination: Screw

Maximum Operating Temperature: +70°C

This is SC-System Isolating Amplifier/Splitter Signal Conditioner 0 → 20 mA 4 → 20 mA Input manufactured by Pepperl + Fuchs. The manufacturer part number is S1SD-1Ai-2C. The output signal is a kind of current. The product is available in din rail mount configuration. The product has -25 → +70°c of operating temperature range. Has a 0 → 10 v, 0 → 20 ma, 2 → 10 v, 4 → 20ma of output range. The product s1sd, is a highly preferred choice for users. It has a/an transmitter power supply type module . Typical input range of 0 → 20 ma, 4 → 20ma. The input signal is a kind of current signal. Features 16.8 → 31.2v dc supply voltage. Whereas, the minimum operating temperature of the product is -25°c. The product features screw termination style. It has a maximum operating temperature of +70°c.
