Description
Operating Force: 100g
Minimum Operating Temperature: -55°C
IP Rating: IP40
Contact Current Rating: 10A @ 250V ac
Voltage Rating: 250V
Contact Configuration: SPDT
Case Material: Glass Filled Thermoplastic
Actuator Type: Plunger
Mechanical Life: 1000000Operations
Release Force: 20g
Maximum Operating Temperature: +85°C
Terminal Type: Quick Connect
Contact Material: Silver/ Silver Plated
This is Plunger Microswitch Quick Connect Terminal 10A @ 250V ac SPDT IP40 manufactured by RS PRO. The manufacturer part number is 249-6855. It has a 100g of operating force. Whereas, the minimum operating temperature of the product is -55°c. It is IP rated with ip40. The rated contact current is 10a @ 250v ac. Moreover, the product has a nominal 250v voltage rating. The contact is equipped with spdt configuration. The casing is constructed from highly stable glass filled thermoplastic material. The product carries plunger actuator. The product also provide mechanical stability with 1000000operations. It carries a release force of 20g. It has a maximum operating temperature of +85°c. The terminal is a quick connect type. The product is made from sturdy silver/ silver plated materials.
