Telemecanique Sensors 4PDT Non-Latching Relay Plug In, 24V dc Coil, 8 A

Description

Dimensions: 21 x 47.7 x 27mm

Coil Voltage: 24 V dc

Coil Resistance: 650 Ω

Life: 100000 cycles

Standards Met: CE, CSA, EN/IEC, GOST, Lloyd’s, REACH, RoHS Compliant, UL

Coil Power: 900mW

Maximum Switching Power DC: 168 W

Maximum Operating Temperature: +55°C

Terminal Type: Plug In

Operating Temperature Range: -40 → +55°C

Switching Current: 8 A

Contact Configuration: 4PDT

Depth: 47.7mm Mounting Type: Plug In Series: RXM Length: 21mm Height: 27mm Maximum Switching Voltage AC: 250V Minimum Operating Temperature: -40°C Maximum Switching Power AC: 1.5 kVA Number of Poles: 4 Contact Material: Silver Alloy

This is 4PDT Non-Latching Relay Plug In 24V dc Coil 8 A manufactured by Telemecanique Sensors. The manufacturer part number is RXM4AB2BD. The given dimensions of the product include 21 x 47.7 x 27mm. The coil voltage of the product is 24 v dc. It holds up to 650 ω coil resistance. It is capable of doing 100000 cycles in a lifetime . The product complies with all safety standards, such as ce, csa, en/iec, gost, lloyd’s, reach, rohs compliant, ul. Robust coil power of 900mw. It bears a maximum 168 w of DC switching power. It has a maximum operating temperature of +55°c. The terminal is a plug in type. The product has -40 → +55°c of operating temperature range. It is integrated with 8 a switching current. The contact is equipped with 4pdt configuration. The product comes in 47.7mm depth. The product is available in plug in configuration. The product rxm, is a highly preferred choice for users. Its accurate length is 21mm. In addition, the height is 27mm. It has a maximum AC switching voltage of 250v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 1.5 kva. It has equipped with 4 poles. The product is made from sturdy silver alloy materials.
