Thermal Interface Sheet, Q-Pad II, 2.5W/m·K, 12 x 12in 0.152mm, Self-Adhesive

Description

Self-Adhesive: Yes

Thermal Conductivity: 2.5W/m·K

Dimensions: 12 x 12in

Operating Temperature Range: -60 → +180 °C

Material: Q-Pad II

Thickness: 0.152mm

Width: 12in

Length: 12in

Minimum Operating Temperature: -60°C

Material Trade Name: Q-Pad II

Maximum Operating Temperature: +180°C

Hardness: Shore A 93

Adhesive: Adhesive – One Side HTSUS: 8546.90.0000 RoHS Status: ROHS3 Compliant Thickness: 0.0060″ (0.152mm) Usage: TO-220 Type: Pad, Sheet Material: Sil-Pad Rubber, Aluminum CoatedManufacturer: Bergquist Thermal Conductivity: 2.5W/m-K Outline: 304.80mm x 304.80mm Backing, Carrier: Sil-Pad Thermal Resistivity: 0.22°C/W Moisture Sensitivity Level (MSL): 1 (Unlimited) standardLeadTime: 10 Weeks Color: Black Series: Q-Pad® II Packaging: Bulk Shape: Square Base Product Number: QII-0 ECCN: EAR99

This is Thermal Interface Sheet Q-Pad II 2.5W/m·K 12 x 12in 0.152mm Self-Adhesive manufactured by Bergquist. The manufacturer part number is QII-0.006-AC-1212. Additionally, it is self-adhesive yes . It features thermal conductivity of 2.5w/m·k. The given dimensions of the product include 12 x 12in. The product has -60 → +180 °c of operating temperature range. The product is made from highly stable and reliable q-pad ii. It is 0.152mm thick. Furthermore, the product is 12in wide. Its accurate length is 12in. Whereas, the minimum operating temperature of the product is -60°c. The material trade name is q-pad ii . It has a maximum operating temperature of +180°c. It features shore a 93 hardness. The product is a splendid adhesive – one side adhesive. It is assigned with possible HTSUS value of 8546.90.0000. The product is rohs3 compliant. It is 0.0060″ (0.152mm) thick. The product’s typical Applications include uses in to-220. It comes in pad, sheet configuration. The product is made from highly stable and reliable sil-pad rubber, aluminum coated. The bergquist’s product offers user-desired applications. It features thermal conductivity of 2.5w/m-k. The given outline of the product is 304.80mm x 304.80mm. The product backing is made from an excellent sil-pad. Features 0.22°c/w thermal resistivity. Its typical moisture sensitivity level is 1 (unlimited). It has a long 10 weeks standard lead time. It has a classic black colour. The product q-pad® ii, is a highly preferred choice for users. In addition, bulk is the available packaging type of the product. It is a square product with unique specifications. Moreover, it corresponds to qii-0, a base product number of the product. The product is designated with the ear99 code number.
