TRACOPOWER TEP 60UIR 60W Isolated DC-DC Converter Through Hole, Voltage in 9 → 75 V dc, Railway Approved

Description

Isolation Voltage: 3kV

Minimum Temperature: -40°C

Isolated: Yes

Width: 36.8mm

Maximum Temperature: +85°C

Load Regulation: 0.001

Standards Met: EN 62368-1

Railway Approved: Yes

Efficiency: 89%

Number of Outputs: 1

Output Voltage Adjustment Range: -20 → +10%

Package: Quarter Brick

Length: 57.9mm Medical Approved: No Output Current: 12A Mounting Type: PCB Mount Series: TEP 60UIR Input Voltage Range: 9 → 75 V dc Depth: 12.7mm Output Voltage: 5V dc Input Voltage Nominal: 36 V dc Power Rating: 60W

This is TEP 60UIR 60W Isolated DC-DC Converter Through Hole Voltage in 9 → 75 V dc Railway Approved manufactured by TRACOPOWER. The manufacturer part number is TEP 60-3611UIR. It has 3kv isolation voltage. While its minimum temperature is -40°c. Isolated options – yes. Furthermore, the product is 36.8mm wide. The product has +85°c maximum temperature. Load Regulation – 0.001. The product complies with all safety standards, such as en 62368-1. The product is railway approved yes . It is a highly efficient product with an 89% of high efficiency. Additionally, the product is supplied with 1 outputs. It has -20 → +10% of output voltage adjustment range. It is shipped in quarter brick package . Its accurate length is 57.9mm. Medical Approval – no. It carries 12a output current. The product is available in pcb mount configuration. The product tep 60uir, is a highly preferred choice for users. It has 9 → 75 v dc of input voltage range. The product comes in 12.7mm depth. Features a 5v dc output voltage. It has 36 v dc of nominal input voltage. Feature 60w of power rating.
