Vishay VS-GBPC3508A, Bridge Rectifier, 35A 800V, 4-Pin GBPC-A

Description

Peak Reverse Current: 5µA

Dimensions: 28.6 x 28.6 x 7.7mm

Bridge Type: Single Phase

Peak Non-Repetitive Forward Surge Current: 500A

Peak Average Forward Current: 35A

Height: 7.7mm

Peak Forward Voltage: 1.1V

Width: 28.6mm

Length: 28.6mm

Package Type: GBPC-A

Peak Reverse Repetitive Voltage: 800V

Minimum Operating Temperature: -55 °C

Mounting Type: Screw Mount Configuration: Single Maximum Operating Temperature: +150 °C Pin Count: 4

This is Bridge Rectifier 35A 800V 4-Pin GBPC-A manufactured by Vishay. The manufacturer part number is VS-GBPC3508A. It has a typical 5µa peak reverse current . The given dimensions of the product include 28.6 x 28.6 x 7.7mm. It contains a/an single phase type bridge . Moreover, a bespoke product has 500a peak non-repetitive forward surge current. Additionally, it has about 35a of peak average forward current . In addition, the height is 7.7mm. Whereas, the peak forward voltage is about 1.1v . Furthermore, the product is 28.6mm wide. Its accurate length is 28.6mm. The package is a sort of gbpc-a. While having the peak reverse repetitive 800v. Whereas, the minimum operating temperature of the product is -55 °c. The product is available in screw mount configuration. The product is available in single configuration. It has a maximum operating temperature of +150 °c. It contains 4 pins.
