Kübler HTL, RS422, TTL Output, Signal Converter

Description

Output Signal Type: HTL, RS-422, TTL

Mounting Type: DIN Rail Mount

Operating Temperature Range: 0 → +45°C

Output Range: 30mA

Module Type: Interface Converter

Input Range: 500 kHz, 10 → 30V

Input Signal Type: HTL, RS-422, TTL

Supply Voltage: 5 → 30V dc

Minimum Operating Temperature: 0°C

Interface: RS422

Termination: Screw

Maximum Operating Temperature: +45°C

This is HTL RS422 TTL Output Signal Converter manufactured by Kübler. The manufacturer part number is 8.PW.1D-1D. The output signal is a kind of htl, rs-422, ttl. The product is available in din rail mount configuration. The product has 0 → +45°c of operating temperature range. Has a 30ma of output range. It has a/an interface converter type module . Typical input range of 500 khz, 10 → 30v. The input signal is a kind of htl, rs-422, ttl signal. Features 5 → 30v dc supply voltage. Whereas, the minimum operating temperature of the product is 0°c. A bespoke product is rs422 interface. The product features screw termination style. It has a maximum operating temperature of +45°c.
