Switch Mode DIN Rail Panel Mount Power Supply, 60W, 24V dc/ 2.5A

Description

Maximum Temperature: +60°C

AC or DC Output Voltage: dc

Dimensions: 125 x 32.5 x 125mm

Minimum Temperature: 0°C

AC or DC Input Voltage: ac

Width: 32.5mm

MTBF: 3153082h

Electrical Phase: 1

Type: Switched Mode

Load Regulation: 0.5%

Standards Met: CE

Efficiency: 85%

Input Voltage: 93 → 132V ac Number of Outputs: 1 Output Voltage Adjustment Range: 22.8 → 26.4V Ripple And Noise: 150mV Pk-Pk Depth: 120mm Mounting Type: DIN Rail Mount Output Current: 2.5A Series: SITOP PSU100L Height: 125mm Output Voltage: 24V dc Power Rating: 60W

This is Switch Mode DIN Rail Panel Mount Power Supply 60W 24V dc/ 2.5A manufactured by Siemens. The manufacturer part number is 6EP1332-1LB00. The product has +60°c maximum temperature. It has a/an dc output voltage . The given dimensions of the product include 125 x 32.5 x 125mm. While its minimum temperature is 0°c. It has ac input voltage. Furthermore, the product is 32.5mm wide. The MTBF values include 3153082h. Its electrical phase configuration includes 1. It comes in switched mode configuration. Load Regulation – 0.5%. The product complies with all safety standards, such as ce. It is a highly efficient product with an 85% of high efficiency. Its input voltage is 93 → 132v ac. Additionally, the product is supplied with 1 outputs. It has 22.8 → 26.4v of output voltage adjustment range. Carries 150mv pk-pk ripple and noise. The product comes in 120mm depth. The product is available in din rail mount configuration. It carries 2.5a output current. The product sitop psu100l, is a highly preferred choice for users. In addition, the height is 125mm. Features a 24v dc output voltage. Feature 60w of power rating.
